機器特點

◆本機是對合金圓鋸片焊接齒臺進行研磨的專用自動化設備。

◆機械手上下鋸片，操作簡潔方便，一人可操作10臺以上。

◆行程由電機提供動力，可精卻控制研磨深度。

◆可加工駝峰齒等特殊齒型。

Machine features

    1.This machine is a specialized automated equipment for grinding the welding tooth table of alloy circular saw blades.

    2.Using a robotic arm to move the saw blade up and down, the operation is simple and convenient, and one person can operate more than 10 machines.

    3.The stroke is powered by an electric motor, which can accurately control the grinding depth.

    4.Can process special tooth shapes such as hump teeth.

技術參數Technical parameter

◆鋸片直徑Blade Diameter   φ110—φ400mm

◆齒距范圍Range of tooth pitch   7—50mm

◆適用齒厚Applicable tooth thickness   ≤3.5mm

◆砂輪規格Grinding wheel specifications   φ255×φ25.4×2.5mm

◆砂輪行程Grinding wheel stroke   0—25mm

◆工作次數Work frequency   40—60T/min

◆工作氣壓Working air pressure   ≥0.45MPa

◆電源電壓supply voltage  AC380V50Hz  V

◆功    率Power   2.5KW

◆重    量Weight   600Kg

◆機床尺寸Machine tool dimensions    1050×1300×1800mm
